10kV配电自动化整定原则(实用).ppt

  • 2026-04-06 12:19:37
10kV配电自动化整定原则(实用).ppt
该资料已在星球更新，会员可扫码直接下载
本文下载方式见文末
以下是内容介绍

点击领取>>油浸式电力变压器现场交接试验(实用).ppt

配电自动化是指以配电网一次网架和设备为基础，综合利用计算机、信息及通信等技术，并通过与相关应用系统的信息集成，实现对配电网的监测、控制和快速故障隔离，为配电管理系统提供实时数据支撑。通过快速故障处理，提高供电可靠性；通过优化运行方式，改善供电质量、提升电网运营效率和效益。

配电自动化是如何实现快速故障隔离的呢？
